Table Type
HORIZONTAL BORING MILL – W100 TOS VARNSDORF
Ref. No.89
- Brand
- TOS VARNSDORF
- Model
- W100
- Condition
- used
Spindle Diameter:100 mm
X Travel:1600 mm
Y Travel:1120 mm
Z Travel:1250 mm
W Travel:900 mm
Table Size:1250 × 1250 mm
Max Table Load:3 Tons
Max Facing Diameter:900 mm
Spindle Speed:7.1 – 1120 RPM
Spindle Taper:ISO 50
Facing Chuck Diameter:600 mm
Facing Chuck Speed:7.1 – 224 RPM
Slide Travel:210 mm
Total Power:15 kW
Machine Weight:14000 kg
Machine specifications
- Manufacturer
- TOS VARNSDORF
- Model
- W100
- Condition
- used
- Name
- HORIZONTAL BORING MILL – W100
- Power
- 15 kW
- Brand
- TOS VARNSDORF
- Model
- W100
- W Travel
- 900 mm
- X Travel
- 1600 mm
- Y Travel
- 1120 mm
- Z Travel
- 1250 mm
- Table Size
- 1250 × 1250 mm
- MachineType
- Conventional
- Slide Travel
- 210 mm
- Spindle Speed
- 7.1 – 1120 RPM
- Spindle Taper
- ISO 50
- Machine Weight
- 14000 kg
- Max Table Load
- 3 Tons
- Spindle Diameter
- 100 mm
- Facing Chuck Speed
- 7.1 – 224 RPM
- Max Facing Diameter
- 900 mm
- Facing Chuck Diameter
- 600 mm
