Turning and Milling Centres
CNC Vertical Turret Lathe TITAN SC2000
Ref. No.273
- Brand
- TITAN
- Model
- SC2000
- Condition
- used
CNC Vertical Turret Lathe
Brand:TITAN
Model:SC2000
Table Diameter:2000 mm
Maximum Diameter:2200 mm
Maximum Height:1500 mm
Table Rotation Speed:1.55–140 rpm
Maximum Load:12000 ks
Maximum Load:12 Ton
Z-Axis Travel:1250 mm
Revolver Turret Vertical Travel:760 mm
RAM Head Vertical Travel:1200 mm
Side Head Horizontal Travel:700 mm
Side Head Vertical Travel:1500 mm
Voltage:400 V
Frequency:50 Hz
Machine Dimensions (L × W × H):4200 × 4300 × 4600 mm
Machine Weight:31.35 Ton
Machine specifications
- Manufacturer
- TITAN
- Model
- SC2000
- Condition
- used
- Brand
- TITAN
- Model
- SC2000
- Voltage
- 400 V
- Category
- CNC Machines
- Frequency
- 50 Hz
- Subcategory
- CNC Turning Centres
- Machine Name
- CNC Vertical Turret Lathe
- Maximum Load
- 12000 ks, 12 Ton
- Z Axis Travel
- 1250 mm
- Machine Weight
- 31.35 Ton
- Maximum Height
- 1500 mm
- Table Diameter
- 2000 mm
- Maximum Diameter
- 2200 mm
- Table Rotation Speed
- 1.55–140 rpm
- Machine Dimensions L W H
- 4200 × 4300 × 4600 mm
- Ram Head Vertical Travel
- 1200 mm
- Side Head Vertical Travel
- 1500 mm
- Side Head Horizontal Travel
- 700 mm
- Revolver Turret Vertical Travel
- 760 mm
